VERTEX C PISTON KITS VTK23119C
Models More Information CC Year
Fantic XE Euro5 125 125 21/21
Fantic XX Euro5 125 125 21/21
Yamaha YZ 125 125 05/20
Vertex Piston Kit (C), Top End Gaskets, and Needle Cage - 2-Stroke
ATTENTION: Vertex 1-ring piston kit.
The Vertex Top End Piston Kit provides everything needed for top end engine rebuilds, eliminating the hassle of sourcing separate components.
The kit includes a Vertex piston, 1 ring, needle cage, gudgeon pin, circlips, and a top end gasket kit. Piston A utilizes the standard cylinder bore to maximize power and performance.
VERTEX C PISTON KITS VTK23119C
Models More Information CC Year
Fantic XE Euro5 125 125 21/21
Fantic XX Euro5 125 125 21/21
Yamaha YZ 125 125 05/20
Vertex Piston Kit (C), Top End Gaskets, and Needle Cage - 2-Stroke
ATTENTION: Vertex 1-ring piston kit.
The Vertex Top End Piston Kit provides everything needed for top end engine rebuilds, eliminating the hassle of sourcing separate components.
The kit includes a Vertex piston, 1 ring, needle cage, gudgeon pin, circlips, and a top end gasket kit. Piston A utilizes the standard cylinder bore to maximize power and performance.
Vertex Pistons: Vertex pistons are forged from a 2618 aluminum alloy containing copper and magnesium. This forging withstands higher temperatures and improves strength and durability, maximizing power and performance. It also reduces friction.
Vertex Gasket Kits: The gasket kit contains all the gaskets needed to rebuild the upper engine. The kit includes a cylinder head gasket, cylinder base gasket, and exhaust gasket, as well as the O-rings needed to assemble the cylinder and cylinder head.
Cylinder Bore (mm) 54
Displacement (cc) 125
Piston Bore (mm) 53.95
